55
DEU
ENG
FRA
ITA
SPA
NLD
RUS
Temporizzatore digitale Control 2 – Installazione elettrica
Control
Thermostat
AR 20.. C2
AR 40.. C2
Thermostat
AR 20.. K2
AR 40.. K2
E’ possibile collegare
altri regolatori
max. 5 azionatori
A 2xxx5 / A 4xxx5
max. 5 azionatori
A 2xxx5 / A 4xxx5
230 V AC / 0,2 A
carico resistivo ohmico
24 V AC / 1 A
carico resistivo ohmico
230 V AC
N L
24 V AC
L2 L1
