69
DEU
ENG
FRA
ITA
SPA
NLD
RUS
Temporizador digital Control 2 – Instalación eléctrica
Control
Thermostato
AR 20.. C2
AR 40.. C2
Thermostato
AR 20.. K2
AR 40.. K2
Conexión de más
termóstatos posible
max. 5 actuadores
A 2xxx5 / A 4xxx5
max. 5 actuadores
A 2xxx5 / A 4xxx5
230 V AC / 0,2 A
carga óhmica
24 V AC / 1 A
carga óhmica
230 V AC
N L
24 V AC
L2 L1
