Spherical Tip
7.40 mm
0.76 mm
TPA Stop Surface
Section 6: Electrical Continuity Checking
B. Pogo Pin Recommendation – 2.8mm and 6.3mm Terminals
 Pogo Pin Specification – See next page.
