molex MX123 - Electrical Continuity Checking

MX123 Connection System User Manual - AS-34566-001 51
Spherical Tip
5.75 mm
0.53 mm
TPA Stop Surface
Section 6: Electrical Continuity Checking
A. Pogo Pin Recommendation - 0.64mm Terminal
 Pogo Pin Specification – See next page.
