MX123 Connection System User Manual - AS-34566-001 57
2.54
2.54
6.52
2.54
Typ.
44.45
2.80 Pogo
Test Pogo Pin Probing Array
Section 6: Electrical Continuity Checking
C. Pogo Pin Layout Recommendation (73-way)
