MX123 Connection System User Manual - AS-34566-001 9
Section 2: Product Summary
2.80mm Receptacle Terminal
(Yazaki Terminal and Cable Seal)
7116-4152-02 Yazaki 2.8mm RCPT TERM Tin 14 Cable Seal
Correct Orientation
180° Misorientation
Lock-out
90° Misorientation
Lock-out
Orientation Tabs
Orientation of receptacle terminal during insertion to connector
