22
Forward Feed Adjustment Lock Screw
Forward Feed
Adjustment Lock Wheel
Adjusting Backward
Adjusting Forward
+
5
1
Forward Feed Adjustment Indicator
Min. Backward Feed
Max. Forward Feed
Backward
Forward
Feed Finger
M6 Jam Nut and
Fine Adjust Screw
FORWARD AND BACKFEED ADJUSTMENT
Fig. 6
