Molift Smart 150 - Technical Specifications and Data; Specifications and Working Dimensions

BM09201 Molift SMART 150 English - Rev C1/08/10 Page 11 of 20
Technical data
Weight, total:
Ex. battery; 25 kg / incl. battery: 25,8 kg
Material:
Steel and aluminium
Motor:
12 VDC
Battery:
14,4 V NiMH 2,2 Ah, Molift Power Pac
Battery charger:
Mascot type 2215, 10-22 cells NiCd/NiMH
Protection:
IPX4
Number of lifts with fully charged battery:
40 (75 kg/165 lb, 50 cm up/down)
Safe Working Load (SWL):
150 kg (330 lbs)
Lifting height:
0 - 750 mm below user
Lifting speed:
60 mm/sec
Sound level, max A-weighted sound power level:
L
WA
= 49,4 dB
Operating forces:
Buttons on hand control: 1,5 N
Foot pedal: max 300 N
Height of legs:
Max 110 mm
Turning diameter:
1300 mm
Measurement, transport:
1160 x 475 x 355 mm (LxWxH)
Measurement, assembled:
1160 x 1060 mm (LxW)
Measurements in illustrations below are in milli-
metres.
Measurements with lifter in working position
240
700
