• Locate the slide-out motor. It is located in a storage compartment under
the slide-out room (center of room).
• Rotate the lever protruding out of the black housing of the motor assembly (brake
release lever) to disengage brake. NOTE: There is a label showing ENGAGED and
DISENGAGED.
• The room is now free to move. Locate the slide-out rail assemblies (one on each
side of the motor assembly) and 3/4” hex coupling on the end of the drive shaft.
• Using a 3/4” wrench or rachet, crank the room either in or out completely
(depending on your need).
• When the room is fully in (or out) have one person put pressure on the
wrench/rachet to ensure a tight seal while the other person returns the motor
brake lever to the engaged positioin. This will ensure the room is locked into a
sealed position.
• Install transit bars (if so equipped) and take the motorhome to an authorized
dealer for service.
Maintenance
• When the room is out, visually inspect the inner rail assemblies. Check for for-
eign matter of other objects. Remove any debris that may be present.
• If the system squeaks or makes any noise it is permissible to apply a coat of
lithium grease to the rollers and/or bearing sleeves. Wipe off any excess lubri-
cant.
• There is no need to lubricate the gear or gear rack. This system is designed to
operate without lubricant to these components.
Monarch
3-24
Appliances & Equipment
Appliances & Equipment
MONACO
2000
! WARNING !
When the slide-out room motor brake lever is disengaged the room will not
lock into place, and therefore will not be sealed from the outdoors.
! CAUTION !
Do not work on your systems unless the battery is disconnected.
