Fuse Box Under Dash
NOTE: Fuse Number’s 1, 3, 10, 11, 12, 15,1 6, 17 are not used.
Monarch 6-9
MONACO
2000
Electrical Systems
Electrical Systems
Fuse Location Size Circuit
2 8.25A Interval Wiper/Washer Windshield Wiper
Washer System
Instrument Panel Warning Lights
4 15A Programmable Speedometer/Odometer
Module, Warning Chime
5 20A Instrument Panel Lamps, Prk/Marker,
Light Module, (POSM)
6 10A Body Builders Accessory Feed (Accessory
and Run)
7 20A Overdrive Cancel Switch, Turn Signals
8 15A Body Builders Accessory Feed (Run Only)
9 20A Brake Pressure Switch, Hazard Lamp,
Stop Lamps
13 5A Instrument Panel Illumination
14 5A Not Used (For Radio Feed - see Inside
Fuse Panel)
18 15A Not Used by Body Builder
