Fuse Box Behind Grille on Firewall
NOTE: Fuses G, H, I, J, T, U are not used. Relay #5 is not used.
Monarch
6-10
Electrical Systems
Electrical Systems
MONACO
2000
Fuse Location Size Circuit
A 15A Not Used (For Cigar Lighter - See Front
Distribution Panel)
B 20A Flash to Pass, Daytime Running Lamps
C 20A Horn Relay, Slip Ring Assembly
D 20A Body Builder Battery Accessory Feed
E 15A Heated Exhaust Gas Oxygen Sensor,
Back-up Lamps, Blower Relay Coil
F 10A Speed Control
K 20 MAXI P R N D L Sensor, Starter Motor Relay,
T.F.I. Module
L Diode EEC Relay
M 30 MAXI EEC Relay
N 60 MAXI Ignition Switch
O 30 MAXI Electric Brake
P 50 MAXI Not Used (For Blower Motor Feed - See
Front Distribution Panel)
Q 60 MAXI Head Lamps, Main Light Switch, PSOM
R 20 MAXI Fuel Pump Relay
S 20 MAXI Body Builder Battery Feed
V 20 MAXI TFI Ignition Module, Ignition Coil,
Distributor, Radio Capacitor, EEC Relay Coil
Relay #1 Electronic Engine Control (EEC)
Relay #2 Fuel Pump Relay
Relay #3 Horn Relay
Relay #4 Not Used
