Monark 927 E - Page 15

Monark 927 E
15
Pos. Qty. Art. No. Description Pos. Qty. Art. No. Description
1 1 9309-53 Frame cover, left 18 4 9309-51 Plastic cap
2 1 9309-4 Aluminium prole 19 4 9328-26 Rubber foot
3 1 9309-52 Frame cover, right 20 4 5845 Locking nut
4 8 5675-9 Screw M5x6,5 21 16 5673-9 Screw M5x12
5 1 9309-131 Bushing f. saddle post 22 1 9309-74 Control cover
6 1 4992-7 Saddle 23 4 9337-38 Screw M8x16
7 1 5605-1 Screw M8x46 24 1 9328-2 Handlebar clamp
8 1 5864 Washer M8 25 1 9309-160 Digital meter, complete
9 1 5844 Locking nut 26 1 9000-105 Screw M5x10
10 1 9308-132 Locking knob 27 1 5864 Washer
11 1 9328-37 Transport wheel compl. (pair) 28 1 9326-89 Distance
12 1 9328-6 Support tube, rear 29 1 9326-707 Lever, complete
13 1 9328-130 Saddle post 30 1 9309-9 Handlebar, complete
14 1 76424 Foot straps (pair) 31 1 9309-71 -Handgrip (pair)
15 1 74435 Pedal (pair) 1 9309-150 Screw set
16 4 9300-12 Screw M8x16 1 9309-550 Decal set
17 1 9328-5 Support tube, front 1 9309-78 Handlebar black complete with
clamp and handle
From serial number: WBK 271946
