Spare parts list
Pos. Qty. Art. No. Description Pos. Qty. Art. No. Description
1 1 9309-30 Flywheel 12 1 9326-54 Chain, 100 L
2 1 9309-45 Wheel suspension complete set 13 1 8966-175 BB cartridge bearing
3 1 9000-12 -Chain adjuster (pair) 14 1 9328-162 Sensor with 1750 mm cable
4 1 76441 -Sprocket 15 1 9309-3 Joint clamp
5 2 19001-6 -Bearing 6001-2z 16 1 9328-1 Frame
6 1 9309-18 -Axle 17 1 8966-176 Support casing for BB-bracket
7 1 9309-65 Brake belt, complete 18 1 9309-10 Cable bracket
8 1 9371-16 Magnet 19 4 5673-9 Screw M5x12
9 2 8523-2 Dust cover for crank 20 1 9309-72 Tension device, complete
10 2 8523-115 Screw M8 x 1 x 20 21 1 5698 Screw M5 x 55
11 1 9300-430 Steel crank set, complete 22 1 9309-24 Tension cable, complete
23 1 9328-33 Adaptor M20/M16
From serial number: WBK 271946
