Remove the the four screws (1) that holds the front cover in place.
Lift the cover so that you can access the electric unit (2) that is located on the left side of the bike.
Electric unit
1. Cable from display
2. Right shifters
3. Left shifters
4. Other functions (sensor etc. )
Towards the ywheel
Cables from the shifters and display are pulled trough the hole on the frames top left side,
In towards the electric unit. Cables are mounted accordingly to the picture below.
