The user's heart rate can be measured with a chestbelt that
detects the pulse of the heart. For the heart rate to show in
the display you need to use a heart rate sensor with ANT+.
For a correct measurement of the heart rate you need to
position the sensor correctly and that the skin is clean.
HEART RATE FUNCTION
Break lock to chestbelt
The display saves the last used chestbelt. This means that
you do not need to connect to a chestbelt every time you
ride the same bike. To break this go into "Settings" and press
"reset ant lock" and the text changes to "no pulse….” Then
the display can search for and lock to a new chestbelt.
Settings
Break lock to chestbelt
NOTE!
Electromagnetic waves may disturb heart rate
function. Cellular phones are not allowed to be
used near the bike during test.
SCALE - ZERO ADJUSTMENT
Fig: Scale adjustment
1) Screw
2) Kp-scale
3) 0-index
Check that 0-index (3) on the scale (2) is in line with the pendulum pointer when the bike is at a stand still and the brake belt
is loose. Loosen the brake belt by lifting the pendulum over 6kp, the motor will release the workload. If the pendulum is not
aligned with the 0-index, the scale musst be adjusted. Loosen the pole screw and adjust the scale. Tighten the pole screw (1)
after adjustment. See Fig: Scale adjustment.
