CDVSC7 & CDV7 Series Gas Fireplace
18
69D3011
3"
1"
1"
1"
FP2288
TV rear vent
Figure 14 -
Combustible Clearances for Vent Pipe
A Minimum of 3" Clearance
to the Top Is Required
Along Horizontal Length
until Flue Pipe Penetrates
Outside Wall.
A Minimum 1"
C l e a r a n c e to
Co m b u s t i b l e s
P e r m i t t e d Al l
Around Flue at
Outside Wall
until
the flue penetrates the outside wall.
until
the flue penetrates the outside wall.
1"
3"
1"
1"
FP2289
RV rear vent
A Minimum of 3" Clearance
to the Top Is Required Along
Horizontal Length until Flue
Pipe Penetrates Outside
Wall.
A Minimum 1" Clearance
to Combustibles Permitted
All Around Flue at Outside
Wall
FP88
FP89
