Monessen Hearth CDV7 - Optional Fan;Blower System - SCS; BLOTSC Wiring Diagram

CDVSC7 & CDV7 Series Gas Fireplace
69D3011
39
To Junction Box
In Fireplace
WHITE
BLACK
WHITE
BLACK
BLACK
WHITE
GREEN
Connector
Pin To Contro l Box
{
{
Optional
Light
Optional
AUX
Blower (300w Max)
FP2103
AC fan wiring
Figure 57 -
Blower Wiring Diagram
FP103





        

        



    


      


   
     


    


The BLOTSC Blower Kit requires the SCSACM A/C Mod-
ule and the TSFSC remote to install and operate this kit.
Refer to blower instructions for installation.
