CDVSC7 & CDV7 Series Gas Fireplace
60
69D3011


           
           
1. Gas Valve Assy. 1 80D0001 80D000 80D0001 80D000 80D0001 80D000 80D0001 80D000
. Pilot Assembly 1 80D0006 80D0007 80D0006 80D0007 80D0006 80D0007 80D0006 80D0007
3. Control Box 1 80D0018 80D0019 80D0018 80D0019 80D0018 80D0019 80D0018 80D0019
4. Command Center 1 80D0005 80D0005 80D0005 80D0005 80D0005 80D0005 80D0005 80D0005
5. Burner Tube 1 0301096 0301096 54D609 54D609 54D6004 54D6004 54D6004 54D6004
6. Flexhose with
Shutoff Valve 1 69D0030 69D0030 69D0030 69D0030 69D0030 69D0030 69D0030 69D0030
7. Injector 1 58D0371 0301196 58D0371 69D06 54D006 69D0079 0H3155 0H3156
8. Burner Assembly 1 0300786 0300786 54D000 54D000 54D0001 54D0001 54D039 54D039
9. Venturi 1 69D1119 69D106 69D1119 69D106 69D1119 69D106 69D1119 69D106
10. Wire Valve Control
(not shown) 1 80D0010 80D0010 80D0010 80D0010 80D0010 80D0010 80D0010 80D0010
11. Wire Command Ctr
Control Box ' 1 80D0008 80D0008 80D0008 80D0008 80D0008 80D0008 80D0008 80D0008
(not shown)
1. A/C Adapter (6 Volt) 1 80D0041 80D0041 80D0041 80D0041 80D0041 80D0041 80D0041 80D0041

13. Hand Held Remote Control w/ HI/LO & Timer RMSC
14. Hand Held Remote Control w/HI/LO & Tstat RTSC
15. Touch Screen Remote w/Optional Light, Blower and Auxiliary Control TSFSC
16. Touch Screen Remote Hi/Lo and Timer TSMSC
17. Touch Screen Remote Hi/Lo and TStat TSTSC
18. Wall Thermostat ON/OFF (not shown) WT
19. SCS Wall Mount Extension Kit (15' wire, rough-in box, wall cover) (not shown) SCSWEK
0. SCS AC Module (*Optional Blower, Light & Aux. Control) SCSACM


CDVR33NSC7 Kit #CDVR3311CKPS
CDVT33NSC7 Kit #CDVT33CKPS
CDV(R,T)36NSC7 Kit #CDV36CKPS
CDV(R,T)4NSC7 Kit #CDV4CKPS
CDV(R,T)47NSC7 Kit #CDV4CKPS

CDVR33PSC7 Kit #CDVR3311CKNS
CDVT33PSC7 Kit #CDVT33CKNS
CDV(R,T)36PSC7 Kit #CDV36CKNS
CDV(R,T)4PSC7 Kit #CDV4CKNS
CDV(R,T)47PSC7 Kit #CDV47CKNS
 TSFSC must be used with SCS A/C Module to control blower, lights and aux.
