Mongoose Q-U720AC - Page 31

29
Connector E
PIN
DEFINITION
E1
SPEED
E2
GROUND
E3
PARKING
E4
AMP_ACC
E5
NC
E6
NC
Connector F
PIN
DEFINITION
F1
GROUND
F2
NC
F3
NC
F4
NC
F5
GROUND
F6
EXT ACC/CAMERA POWER 12V
F7
NC
F8
VIDEO IN
F9
NC
F10
NC
