Mongoose Q-U720AC - Page 32

30
Connector G
PIN
DEFINITION
G1
Rear R[-]
G2
Front L[+]
G3
Rear R[+]
G4
Front L[-]
G5
Rear L[+]
G6
Front R[+]
G7
Rear L[-]
G8
Front R[-]
G9
ANT.Power
G10
KEY A
G11
KEY B
G12
REVERSE
G13
ILL
G14
ACC
G15
BATTERY[+]
G16
GROUND
