17
Channel Levels
This allows you to adjust the output levels of the virtual
centre, surround and sub woofer. They each have
independent attenuation and gain from -10 to +10dB
and will be the same for each input.
The virtual sub has the added ability to be turned off
as well. When the virtual sub is turned on, the LFE
channel will be output from the ASB-2 and the sub-
woofer (if there is one connected). When it is turned
off, the LFE will only be output through the external
sub-woofer.
Sub Out
Here you set the sub woofer output crossover
frequency. The frequency you set will depend on your
tastes and room, but we would recommend setting it
to 80Hz.
Power Options
Here you have a few different options to configure; the
auto standby time, HDMI pass through and front LED
brightness.
Auto Standby Time
The auto standby time option allows you to set
a period of time that it will take before the ASB-2
automatically turns itself off. This can be 15, 30, 45,
60 minutes, or Off. When set to Off, it will only turn off
when the standby button on the remote or product is
pressed. The standby function can be controlled by
the TV, should it have this function. You will need to
set the auto off timer to off if you are going to control
it in this way.
Standby HDMI
Standby HDMI enables the ASB-2 to be turned on
and off by the TV it is connected to. The TV will need
to have its version of HDMI Power Control enabled for
this to work.
HDMI pass through is also bundled in to this option. It
will allow sound and picture to pass through the ASB-
2 when it is in standby mode. This means that the
source can be watched on the TV without the need to
turn the ASB-2 on.
INPUT SELECT
EQUALISATION
OSD LANGUAGE
FIRMWARE UPDATE
CHANNEL LEVELS
SUB OUT
POWER OPTIONS
To Next Page
