Specications
PL100 II PL200 II PL300 II PL500 II PL150C II PL350C II
System Configuration 2 Way – 2 driver 3 Way – 4 driver 3 Way – 4 driver 3 Way – 7 driver 2.5 Way – 3 driver 3 Way – 4 driver
Frequency Response. 40Hz – 100kHz 35Hz-100kHz 28Hz – 100kHz 22Hz- 100kHz 45Hz-100kHz 32Hz- 100kHz
Sensitivity (1W@1M). 88dB 90dB 90dB 91dB 89dB 90dB
Nominal Impedance
6 Ohm
(4.5 Ohm Min @ 160Hz)
4 Ohm
(4.0 Ohm Min @ 135Hz)
4 Ohm
(4.2 Ohm Min @ 111Hz)
4 Ohm
(4.2 Ohm Min @ 120Hz)
6 Ohm
(4.5 Ohm Min @ 170Hz)
4 Ohm
(4.0 Ohm Min @ 115Hz)
Maximum SPL
(per pair, in room)
111.8dBA 117dBA 117.8dBA 120dBA 112dBA 114dBA
Power Handling (RMS) 120W 250W 300W 400W 200W 250W
Recommended
amplifier power into 4
Ohms (RMS)
60-120W 100-250W 100-300W 150-400W 60-200W 100-250W
System Alignments
Single rear HiVe®II port
technology
Two HiVe®II ports technology
Sealed Mid-range TLE
enclosure
Two HiVe®II ports technology
Sealed Mid-range TLE
enclosure
Four HiVe®II ports technology
Sealed Mid-range TLE
enclosure
Single rear HiVe®II port
technology
Two HiVe®II ports technology
Sealed Mid-range TLE
enclosure
Mid - H.F Crossover
Frequency
3.0kHz 3.9kHz 3.4kHz 3.6kHz 3.0kHz 3.3kHz
Bass - Midrange
Crossover Frequency
N/A 750Hz 500Hz 460Hz 600Hz (-6dB LF) 780Hz
Drive unit Complement
1 x 6.5” RDT®II bass/mid-
range driver
1 x MPD high frequency
transducer
2 x 6.5” long-throw RDT®II
bass drivers
1 x 4” RDT®II mid-range driver
1 x MPD high frequency
transducer
2 x 8” long-throw RDT®II bass
drivers
1 x 4” RDT®II mid-range driver
1 x MPD high frequency
transducer
4 x 8” long-throw RDT®II
bass drivers
2 x 4” RDT®II mid-range driver
1 x MPD high frequency
transducer
1 x 6.5” RDT®II bass driver
1 x 6.5” RDT®II bass/ mid-
range driver
1 x MPD high frequency
transducer
2 x 8” long-throw RDT®II bass
drivers
1 x 4” RDT®II mid-range driver
1 x MPD high frequency
transducer
External Dimensions
(Including Fixed Plinth
where applicable)
(H x W x D)
370 x 225 x 285 mm
14
9/16
x 8
7/8
x 11
1/4
inch
998 x 360 x 375 mm
39
5/16
x 14
3/16
x 14
3/4
inch
1113 x 410 x 470 mm
43
13/16
x 16
1/8
x 18
1/2
inch
1803 x 504 x 626 mm
71 x 19
13/16
x 24
5/8
inch
225 x 583 x 291.2 mm
22
15/16
x 8
7/8
x 11
7/16
inch
288 x 800 x 368 mm
11
5/16
x 31
1/2
x 14
1/2
inch
External Dimensions
(Including Fixed Plinth,
Feet and Spikes where
applicable) (H x W x D)
N/A
1043 x 360 x 375 mm
39
5/16
x 14
3/16
x 14
3/4
inch
1158 x 410 x 470 mm
43
13/16
x 16
1/8
x 18
1/2
inch
1848 x 504 x 626 mm
71 x 19
13/16
x 24
5/8
inch
N/A N/A
Product Weight
kg (Ibs)
14.94Kg (32lb 14oz) 36.08Kg (79lb 6oz) 54.52Kg (120lb) 99.1Kg (218lb) 23.98Kg (52lb 12oz) 43.02Kg (94lb 10oz)
Finishes Available
Santos Rosewood veneer with piano lacquer.
Ebony veneer with clear piano lacquer or Piano Black lacquer.
Upholstered front baffle in Black Ingleston premium grade leather By Andrew Muirhead.
14 Platinum Series II
Monitor Audio
reserves the
right to alter
specications
without notice.
