Eco Connect+ Convection | 4/5/7/10-Tray | Steam Installation and Operation Manual
74
MONO FG1BX-UK-MAN-0300 | Rev. C23 (July 2023)
Part 2 | Section 3 | Damper (FG159)
Figure 22: Damper (FG159)
Table 14: Item numbers in Figure 22
9 B749-83-003 Damper solenoid L/H oven
B749-83-004 Damper solenoid R/H oven
A 158-02-00300 Damper solenoid bracket
B 158-02-00600 Coupling
NOTE
Part numbers are referenced from electrical drawing M159E25-75000 in the Electrical Manual.
