Eco Connect+ Convection | 4/5/7/10-Tray | Steam Installation and Operation Manual
80
MONO FG1BX-UK-MAN-0300 | Rev. C23 (July 2023)
Part 3 | Section 1 | Motor and Element (FG158)
Figure 27: Motor and Element (FG158)
Table 18: Item numbers in Figure 27
10 B720-74-005 Fan motor unit
11 B847-04-067 Heating element, 240 Vac
B847-04-074 Heating element, 220 Vac
NOTE
Part numbers are referenced from electrical drawing M158E25-75200 in the Electrical Manual.
