24
ZKTR36LH/ZKTR36RH Trim Kit
3/4" Custom Panel
Step 8
Install
grille panel
• Install four of the six larger undercut screw so that the
top of the screws are 1/16" from the surface of the
support.
• Attach the assembled panel to the grille opening by
inserting the four protruding screws into the brackets
on each side.
Back View
Grille Panel Support
1/16"
