Series-specific Accessories and Spare Parts
Spare Parts Size 07 - D682 Proportional Control Valve
Part name Description Material Part number
Service sealing set
for main stage
Contains the following O-rings:
• 4 pieces for ports P, T, A, B, inner Ø 21.89 mm
(0.86 in) x Ø 2.6 mm (0.1 in)
• 2 pieces for ports X, Y, inner Ø 10.82 mm
(0.43 in) x Ø 1.8 mm (0.07 in)
FKM 85 Shore B97215-V6X2-16
NBR 85 and 90 Shore B97215-N6X2-16
Contains the following Kantseals:
• 4 pieces for ports P, T, A, B, inner Ø 21.89 mm
(0.86 in) x ∫ 2.6 mm (0.1 in)
• 2 pieces for ports X, Y, inner Ø 10.82 mm
(0.43 in) x ∫ 1.8 mm (0.07 in)
Kantseal HNBR 85 Shore B97215-S6X2-16
Service sealing set
for pilot valve or
4/2-way solenoid
valve
Contains the following O-rings:
• 4 pieces for ports P, T, A, B, inner Ø 9.25 mm
(0.36 in) x Ø 1.8 mm (0.07 in)
• 1 piece for port Y, inner Ø 7.65 mm (0.3 in) x
Ø 1.8 mm (0.07 in)
FKM 90 Shore B97215-V630F63
HNBR 90 Shore B97215-H630F61
Accessories Size 07 - D682 Proportional Control Valve
Part name Description Remark Part number
Flushing plate P-T or P-T-X or P-T-X-Y adjustable
Mounting screws and O-rings included
AP B YT X
AP B YT X
AP B YT X
-76741-001
Manifold ISO 4401 size 07, ports P, A, B, T with G 1 A,
ports X, Y with G 1/4 A
B46891-001
Mounting screws 2 pieces M6x55, ISO 4762-10.9, tightening
torque 11 Nm (97 lbf in)
A03665-060-055
4 pieces M10x60, ISO 4762-10.9, tightening
torque 54 Nm (40 lbf ft)
A03665-100-060
Shipping plate ISO 4401 size 07 A88833
