Moog D680 Series - Accessories and Spare Parts D685 Series

57Rev. C, April 2017
ORDERING INFORMATION Moog D680 Series Proportional Control Valves
ACCESSORIES AND SPARE PARTS
57
ORDERING INFORMATION
Rev. C, April 2017
Moog D680 Series Proportional Control Valves
ACCESSORIES AND SPARE PARTS
Series-specific Accessories and Spare Parts
Spare Parts Size 10 - D685 Proportional Control Valve
Part name Description Material Part number
Service sealing set
for main stage
Contains the following O-rings:
• 4 pieces for ports P, T, A, B, inner Ø 53.6 mm
(2.11 in) x Ø 3.5 mm (0.14 in)
• 2 pieces for ports X, Y, inner Ø 14 mm
(0.55 in) x Ø 1.8 mm (0.07 in)
FKM 90 Shore B97215-V6X5-32
HNBR 85 Shore B97215-N6X5-32
Contains the following Kantseals:
• 4 pieces for ports P, T, A, B, inner Ø 53.6 mm
(2.11 in) x ∫ 3.5 mm (0.14 in)
• 2 pieces for ports X, Y, inner Ø 14 mm
(0.55 in) x ∫ 1.8 mm (0.07 in)
Kantseal HNBR 85 Shore B97215-S6X5-32
Service sealing set
for pilot valve or
4/2-way solenoid
valve
Contains the following O-rings:
• 4 pieces for ports P, T, A, B, inner Ø 9.25 mm
(0.36 in) x Ø 1.8 mm (0.07 in)
• 1 piece for port Y, inner Ø 7.65 mm (0.3 in) x
Ø 1.8 mm (0.07 in)
FKM 90 Shore B97215-V630F63
HNBR 90 Shore B97215-H630F61
Accessories Size 10 - D685 Proportional Control Valve
Part name Description Part number
Manifold ISO 4401 size 10, ports P, A, B, T with G 1 1/2 A, ports X, Y with G 3/8 A A25856-001
Mounting screws 6 pieces M20x90, ISO 4762-10.9, tightening torque 460 Nm (339 lbf ft) A03665-200-090
Shipping plate ISO 4401 size 10 A03398
