49
GLOBAL MENU PARAMETERS (CONTINUED)
PRESSURE CAL (CONTINUED)
SLEW
This parameter adds a glide time between aftertouch amounts. Increasing the number
will give you a smoother aftertouch response. Lower values will give you a more precise
response. Experiment to find the setting that’s right for you. The default value is 200.
PITCH CV CAL
When this is highlighted, pressing the CURSOR button takes you into the PITCH CV
CALIBRATION sub menu which allows you to run a calibration routine for incoming pitch CV’s.
RECORD 1V
Apply 1 Volt DC to the PITCH CV Input jack and then press SAVE.
RECORD 4V
Apply 4 Volt DC to the PITCH CV Input jack and then press SAVE.
USE DEFAULT
If you are not happy with your own calibration. Press SAVE and the default 1V and 4V
calibration is restored.
VOL CV CAL
When this is highlighted, pressing the CURSOR button takes you into the VOL CV
CALIBRATION SUB MENU which allows you to run a calibration routine for incoming volume CV’s.
RECORD 1V
Apply 1 Volt DC to the VOL CV Input jack and then press SAVE.
RECORD 4V
Apply 4 Volt DC to the VOL CV Input jack and then press SAVE.
USE DEFAULT
If you are not happy with your own calibration. Press SAVE and the default 1V and 4V
calibration is restored.
INIT SETTINGS (GLOBAL MENU 3.2)
When this is highlighted you can press CURSOR to enter a page that allows you to reset the system
settings (everything in the MIDI MENU and GLOBAL MENU) to their default values. To initialize,hold
the SAVE button until it counts down from 5 to 1. If you let go before it passes 1 it will abort the
initialization. If you hold SAVE for the full 5 count the display will confirm that you have initialized the
system settings. NOTE: INIT SETTINGS will NOT erase the factory or user presets, only the MIDI and
GLOBAL settings.
CONTRAST (GLOBAL MENU 3.3)
This parameter changes the display screen’s contrast level. At lower settings the text will appear fainter.
At higher settings the text will appear darker. The appropriate setting is dictated by your viewing angle,
the ambient lighting in the room, and even the temperature of the room. The default is 64%.
MENU WRAP (GLOBAL MENU 3.4)
When set to ON (default) the very last parameter in any menu will then lead back to the very first menu
parameter. When MENU WRAP is set to OFF, then pressing the button will have no effect once
you’ve reached the very last parameter in a menu.
LIGHT SHOW (GLOBAL MENU 3.5)
Amuse your friends and confound your enemies. When set to ON, the front panel LEDs flash in a 1960s
“futuristic” manner. While perfect for breaks, between sets, and television appearances, the default is OFF
since you can’t see any of your button choices when it is animating (although everything is fully functional
when LIGHT SHOW is ON). Use the ARPEGGIATOR RATE knob to change the speed of the light show.
FIRMWARE AND PANEL VERSIONS
The bottom line of this display page shows the current firmware versions installed on your Sub 37.
