Moog Sub 37 User Manual

7
UNPACKING AND INSPECTION
Check the contents of the shipping carton
Be careful when unpacking the Sub 37 so that nothing is lost or damaged. Moog recommends saving
the carton and all packing materials in case you ever need to ship the instrument for any reason.
The Moog Sub 37 ships with the following items:
I. Sub 37 analog synthesizer
II. Power cord
III. Owner’s manual
IV. Registration card
What you will need:
I. A stand or table sufficient to support the Sub 37
II. Either a 1/4 inch instrument cable and amplified speakers or headphones with a 1/4 inch plug
III. A properly wired AC outlet
SETUP AND CONNECTIONS
Place the Sub 37 on a stable surface such as a keyboard stand at a height suitable for playing comfortably.
I
O
Control Voltage
5-Pin DIN MIDI
USB MIDI
External
Audio in

Moog Sub 37 Specifications

General

Type	Analog Synthesizer
Arpeggiator	Yes
Sequencer	Yes, 64-step
CV/Gate	Yes
USB	Yes
Memory	256 Presets
Keyboard	37-note
LFO	2 LFOs
Outputs	Headphone Out
MIDI	In/Out/Thru
Weight	22 lbs
Oscillators	2 Variable Waveshape VCOs
Filter	Moog Ladder Filter with 6/12/18/24 dB per octave slopes
