Moog Sub 37 User Manual

53
CONTROL/PARAMETER MIDI CC # CC VALUE RANGE
BANK SELECT 0
ALWAYS TRANSMITS 0, SHOULD ALWAYS
SEND 0 WHEN SENDING THIS CC
MOD WHEEL 1 [MSB], 33 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
<RESERVED - MIDI BREATH CTRL> 2 [MSB], 34 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
LFO 1 RATE 3 [MSB], 35 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
MOD 1 PITCH AMT 4 [MSB], 36 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
GLIDE TIME 5 [MSB], 37 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
<RESERVED - DATA ENTRY> 6 [MSB], 38 [LSB]
MASTER VOLUME 7 [MSB], 39 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
LFO 2 RATE 8 [MSB], 40 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
OSC 1 WAVE 9 [MSB], 41 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
<RESERVED - MIDI PAN > 10 [MSB], 42 [LSB]
MOD 1 FILTER AMT 11 [MSB], 43 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
OSC 2 FREQ 12 [MSB], 44 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
OSC 2 BEAT FREQ 13 [MSB], 45 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
OSC 2 WAVE 14 [MSB], 46 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
MOD 2 PITCH AMT 15 [MSB], 47 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
MOD 2 FILTER AMT 16 [MSB], 48 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
MOD 2 PGM DEST AMT 17 [MSB], 49 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER MULTIDRIVE 18 [MSB], 50 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER CUTOFF 19 [MSB], 51 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
MOD 1 PGM DEST AMT 20 [MSB], 52 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER RESONANCE 21 [MSB], 53 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER KB AMT 22 [MSB], 54 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER EG ATTACK TIME 23 [MSB], 55 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER EG DECAY TIME 24 [MSB], 56 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER EG SUSTAIN TIME 25 [MSB], 57 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER EG RELEASE TIME 26 [MSB], 58 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
FILTER EG AMT 27 [MSB], 59 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
AMP EG ATTACK TIME 28 [MSB], 60 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
AMP EG DECAY TIME 29 [MSB], 61 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
AMP EG SUSTAIN TIME 30 [MSB], 62 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
AMP EG RELEASE TIME 31 [MSB], 63 [LSB] 0-127 [MSB], 0-16383[MSB,LSB]
BANK SELECT [LSB] 32 0 = PRESET BANKS 1...8,
1 = PRESET BANKS 9...16
HOLD PEDAL/SUSTAIN 64 0 = OFF / 64 = ON
GLIDE 65 0 = OFF / 64 = ON
ARPEGG IATOR L ATCH 69 0 = OFF / 64 = ON
MOD 1 OSC 1/2 SEL 70 0 = OSC1 + OSC2, 43 = OSC1, 85 = OSC2
MOD 1 SOURCE 71 0 = TRIANGLE LFO, 21 = SQUARE LFO,
43 = SAW LFO, 64 = RAMP LFO,
85 = S&H LFO, 107 = F.EG/PGM
MOD 2 SOURCE 72 0 = TRIANGLE LFO, 21 = SQUARE LFO,
43 = SAW LFO, 64 = RAMP LFO,
85 = S&H LFO, 107 = F.EG/PGM

Moog Sub 37 Specifications

General

Type	Analog Synthesizer
Arpeggiator	Yes
Sequencer	Yes, 64-step
CV/Gate	Yes
USB	Yes
Memory	256 Presets
Keyboard	37-note
LFO	2 LFOs
Outputs	Headphone Out
MIDI	In/Out/Thru
Weight	22 lbs
Oscillators	2 Variable Waveshape VCOs
Filter	Moog Ladder Filter with 6/12/18/24 dB per octave slopes
