Moog Sub 37 User Manual

55
CONTROL/PARAMETER MIDI CC # CC VALUE RANGE
AMP EG HOLD 106 0-127
PITCH BEND UP AMOUNT 107 0..+24 SEMITONES
PITCH BEND DOWN AMOUNT 108 0..+24 SEMITONES
FILTER SLOPES (POLES) 109 0 = -6dB, 32 = -12dB, 64 = -18dB,
96 = -24dB
OSC DUO MODE ON/OFF 110 0= OFF / 64 = ON
KB CTRL LO/HI 111 0 = NEITHER, 32 = LO, 64 = HI
FILTER EG MULTI TRIG 112 0 = OFF / 64 = ON
AMP EG MULTI TRIG 113 0 = OFF / 64 = ON
OSC 1 LEVEL 114 0-127
OSC 1 SUB LEVEL 115 0-127
OSC 2 LEVEL 116 0-127
NOISE LEVEL 117 0-127
FEEDBACK/EXT LEVEL 118 0-127
KB TRANSPOSE 119 RECEIVE ONLY: -12…+13 SEMITONES
LOCAL CONTROL ON/OFF 122 0 = OFF / 127 = ON

Moog Sub 37 Specifications

General

Type	Analog Synthesizer
Arpeggiator	Yes
Sequencer	Yes, 64-step
CV/Gate	Yes
USB	Yes
Memory	256 Presets
Keyboard	37-note
LFO	2 LFOs
Outputs	Headphone Out
MIDI	In/Out/Thru
Weight	22 lbs
Oscillators	2 Variable Waveshape VCOs
Filter	Moog Ladder Filter with 6/12/18/24 dB per octave slopes
