Morbark BOXER 532DX - Section 2 - Operating Controls; Component Locations

2.1
Section 2 - Operating Controls
Component Locations
Left Front View
Item No. Description
1 Attachment mounting plate
2 Tilt cylinder
3 Boom
4 Auxiliary hydraulic quick connects
5 Hand grip
6 Operating controls
7 Manual holder
8 Fuel ller cap
9 Lift cylinder
10 Fuel tank
11 Right track assembly
12 Lift cylinder safety lock
13 Hydraulic level check
7
1
2
3
4
5
6
8
9
10
11
13
12
