Morbark BOXER 532DX - Vibration and Noise Data

General Specications
6.2
Units English Metric
Dump Height
60 in. 1524 mm
Ground Speed (Max)
3.0 mph 4.83 kph
Dump Angle
37 deg. 37 deg.
Reach
34 in. 864 mm
Tip Capacity
2100 lb. 952.5 kg
Operating Capacity, 35% of tip load.
735 lb. 333.5 kg
Operating Capacity, 20% of tip load.
1,500 lb. 680.4 kg
Weight (without Bucket) (*w/Bucket)
2410 lb. 1093 kg
Ground Pressure
3.6 psi 0.2531 kg/cm
2
Vibration Data
Engine rpm was set @ 2800 rpm. The hand-arm and whole body vibration measurements
were made with the operator present.
Vibration Test @ hand /arm: Declared value is 4.4 m/s2.
Vibration Test @ whole body: Declared value is 1.3 m/s2.
Noise Data
Tests were performed in accordance with EU Directive 2000/14/EC, in addition to ISO 3744
and ISO 6395. Engine rpm was set @ 2800 rom. The noise measurements were made with
the operator present.
The declared value for the operator is 89 dB LPA.
The Guaranteed SWL value is 102 dB LWA.
