Routine Service and Maintenance
4.18
e. Loosen, but DO NOT remove, the air bleed bolt (Item 2, Figure 4–19).
f. Raise and lower the primer pump handle (Item 1, Figure 4–19) until only diesel fuel
without any air bubbles comes out of the air bleed.
g. Fully tighten the air bleed bolt.
Figure 4-19 Fuel Feed Pump Lever
6. Check battery for signs of leakage and for corrosion on the battery cables.
• On a monthly basis, check the battery (Item 5, Figure 4–20) for signs of leaking
electrolyte. If any signs of damage are visible, remove and replace the battery.
Wear the proper protective clothing when handling the battery. Leaking battery uid
contains acid that can cause burns. Fumes from the leaking uid can cause respiratory
problems.
• To prevent corrosion, spray on a battery protectent and sealer onto both terminals and
cable clamps after cables are installed.
• The electrical system on this machine is a NEGATIVE ground system.
• Check both of the battery cables (Items 1 and 3, Figure 4–20) for signs of damage or
corrosion. Loosen the cable clamps and remove the cable from the battery. Clean the
terminals with a battery brush. Reinstall and secure the cable clamps.
1
2
