Morbark TORNADO 13 - Enclosure Components; Enclosure Component Parts List

*REFER TO CHECK SHEET FIRST
1/99
4
6
7
14
13
12
10
9
19
21
15
16
17
18
22
20
19
25
24
26
8
21
22
2
1
4
3
5
20
11
ITEM QTY. DESCRIPTION
1 1 Right Rear Panel
2 1 Power Take-Off
3 1 Left Rear Panel
4 2 Side Panel
5 1 Rear Panel
6 1 Hood
7 1 Front Wrap
8 1 Base
9 1 Front Engine Mount Plate
10 4 Bolt
11 4 Lockwasher
12 4 Bolt
13 4 Bolt
14 4 Nut
15 8 Bolt
16 8 Lockwasher
17 1 L.H. Bracket
18 1 R.H. Bracket
19 4 Shock Mount Bolt
20 4 Shock Mount
21 4 Shock Mount Washer
22 4 Shock Mount Nut
23 4 Shock Mount Lockwasher
24 2 Rear Mount
25 8 Rear Mount Bolt
26 8 Rear Mount Lockwasher
ITEM QTY. DESCRIPTION
*Note: Order by Engine s/n, & Item number/description requesting.
37
ENCLOSURE COMPONENTS
CATERPILLAR 3054T
ENGINE P/N 29247-204 & 29247-208
