DESCRIPTION OF THE APPLIANCE
The Morco EUP11RS is a room sealed, fan flued instantaneous gas water heater. This means its operation is independent of the room it
is installed in as the air for combustion is obtained from outside the home and the flue gases are expelled outside the home. It is
therefore suitable for use in Leisure Accommodation Vehicles (LAVs) such as boats and caravan holiday homes. We do not recommend
the use of this appliance in motorhomes. Ignition of the flame is electronic and will take place automatically when a hot tap is opened.
The appliance does not store hot water.
The display on the appliance may exhibit “AL” if it does not work correctly. The appliance has the ability to self-diagnose certain faults.
Please refer to the fault code table on page 15 before contacting a Gas Safe Engineer. Some of the faults are a temporary and some
are permanent.
The packaging of the water heater includes:
• Wall mounting bracket with screws and plugs
• 2 flue restrictor rings - 1 x 43mm and 1 x 45mm
Control panel
Fig. 1- Control panel and display
USE OF THE APPLIANCE
Appliance start-up
Following the necessary checks, proceed with the following
operations:
Electrically power the water heater.
Open the gas isolation valve underneath the water heater.
Ensure that there is a water supply to the heater.
Press the power button .
The display shows:
1. Start-up Parameters
2. Symbols test (display all on)
3. The pre-set water temperature
When you open a hot tap or shower, the display shows the current
water temperature, the symbol (in case hot water request in
progress) and the symbol (in case of burner ON) (Fig. 3).
Service toolgate
Display
Button
Power on
Power off
RESET
Water temperature
control knob
1. Presence of fault
2. Presence of flame (flame symbol)
Flame fault (symbol crossed out)
3. Hot water request in progress
4. Set point temperature
Faults / Alarms
5. Not used
6. Not used
6
1
5
2
MENU EXT MEM
4
3
Display
