Morco EUP11RS - Technical Data

14
TECHNICAL DATA
EUP11RS
kW - kcal/h
Nominal heat input (Qn)
21,5 - 18.490
Nominal output power (Pn) 19,3 - 16.604
Minimum heat input (Qm) 9,5 - 8.170
Minimum output power (Pm) 8,6 - 7.353
GAS TYPE
PROPANE
BUTANE
G31
G30
P.C.I. (15° C 1013 mbar) MJ/m
3
88,00 116,09
WI (15° C 1013 mbar) MJ/m
3
70,69 80,58
Consumption (15° C 1013 mbar)
1,67 kg/h
1,70 kg/h
Maximum burner pressure mbar 36,4 28,3
Minimum burner pressure mbar 8,0 6,1
N. nozzle
Ø Main burner nozzle
Nr/mm
18x0,50
+4x0,48
NOx emissions (according to EN26:2015 on H
S
)
mg/kWh
45,1
60,3
Ø Gas connection
“
3/4
BE-FR-GB-IE-IT-ES-NL category - nominal feed pressure
I3P - G31: 37 mbar
BE-ES-FR-GB-IE category - nominal feed pressure
I3B - G30: 30 mbar
ES-FR-GB-IT category - nominal feed pressure
I3R - G30/G31: 28-30/37 mbar
FUMES EXHAUSTION
EUP11RS
G31 G30
Flue gas mass flow rate (min-max)
kg/h
34,005-53,020
42,465-63,644
Flue temperature (max-min)
°C
159 - 96
165 - 101
Air capacity Nm
3
/h 40,741 49,112
Ø flue gas release tube
mm
100/60
FAN PERFORMANCE EUP11RS
Residual head of boiler without pipes
Pa
71
ELECTRICAL CIRCUIT EUP11RS
Power supply voltage
V - Hz
230 – 50
Electric power
W
41
Degree of Protection
IPX5D
INSTALLATION SITE TEMPERATURE
EUP11RS
Minimum working temperature
°C
3
WATER EUP11RS
Domestic water flow limiter
l/min
8
35°C temperature rise above ambient l/min 8
Minimum ignition flow l/min 2
Selectable water temperature
°C
37-60
Minimum pressure
bar
0,13
Maximum pressure bar 10
Ø water connections 1/2”
DIMENSIONS AND WEIGHTS EUP11RS
Height
mm
617
Width
mm
304
Depth
mm
222 (238 with aesthetic)
Weight
Kg
14
Note: cold water temperature of reference 15°C.
