Morgan Schaffer Calisto - Installation Step Summary

31
inches where they enter the fittings. Incorporate at least one shallow bend somewhere in the
tubing to aid installation. Tighten the tubing at the transformer valve to complete the oil
RETURN line installation.
Figure 18: Attaching the Copper Tubing to the OUTLET Port
4. Secure all oil lines against excessive vibration.
