35
Figure 23: Flushing the Oil SUPPLY Tube
5. While maintaining the INLET valve open, remove the Quick Connect Oil Sampling Tube
from the oil SAMPLING port by pushing the locking ring up and pulling the fitting (with
yellow hose) down (See Figure 24).
Figure 24: Disconnecting the Quick Connect Oil Sampling Tube from the Monitor
6. Open the OUTLET valve (left side). At this stage, both transformer valves and both
monitor valves should be open as shown in Figure 25.
