Calisto/Calisto 2 can be set up for local, remote (hard wired) or wireless communication (not part of
this manual).
Calisto/Calisto 2 is supplied with a 1.8 m (6 ft) A/B type USB cable (Refer to Figure 27). The USB
port is dedicated to the monitor configuration, setup and maintenance.
Before connecting the USB cable to the monitor, open the door and access the monitor interface
board. Connect the USB cable to the interface board port (type B) and to your portable computer
port (type A).
Figure 27: 6-Feet Long A/B Type USB Cable
Electrical shock hazard. Only persons with electrical safety training and certification
should install the equipment or open the enclosure once the equipment has been
installed.
