Morgan Schaffer Calisto - Page 89

79
IP67 connection
Isolated to 1500 Vrms (on monitor side only)
Customizable cable length (up to 15 m [50 ft])
Oil and water resistant components
UV stabilized components
Category 5e components
Straight-through pair configuration
Datatuff
®
series cable for harsh environments
Cable jacket: Industrial grade PVC
100% Shielded (Bonded Bedfoil
®
and drain wire)
Conductors: 0.2 mm
2
(AWG 24), solid bare copper
UL1581 rated (-40°C [-40°F]cold bend)
Operating temperature range: -40
o
C to 75C (-40°F to 167°F)
Installation temperature range: -25
o
C to 75C (-13°F to 167°F )
Min. bending radius 2.5 cm (1 inch)
Max. pulling tension 11.3 kg (25 lbs)
Immune to EMC
Fast plug-in and secure type of connectors
