MORTEX G18D SERIES - Replacement Parts List

MORTEX PRODUCTS INC 501 TERMINAL RD FORT WORTH, TX 76106 Page 25
G18D Gas Furnace Parts List
IDENTIFICATION #
IN FIGURE 21
USED ON FURNACE MODEL # PART # QTY DESCRIPTION
1 G18D060, 070,077, 090 R68DD0014 1 PRES URE SWITCH, N.O, .10
2 G18D060, 070,077, 090 R71CA0006 2 ft. SILICON TUBING
3 G18D060, 070,077, 090 R68CA0005 1 LIMIT SWITCH, MANUAL RESET, OPEN 180F
4 G18D060, 070,077, 090 R86GF0050 1 COMBUSTION BLOWER AS Y w/AIR ORIFICES
5 G18D060, 070,077, 091 R68GF0021 1 EMERSON INTEGRATED CONTROL BOARD
6 G18D060, 070,077, 090 R68GF0016 1
GAS VALVE -HSI ELECTRIC IGNITION
(Supersedes R68GF0012)
7 G18D060, 070,077, 090 R86GF0073 1 GAS MANIFOLD PIPE w/VALVE BRACKET
9 G18D060, 070,077, 090 R86GF0052 1 HEAT EXCHANGER & GASKETS
10 ALL R87TEU001 1 SINGLE FLAME BAFFLE
12 G18D060, 070,077, 090 R68GF0004 1 FLAME SENSOR
13 G18D060, 070,077, 090 R68DD0009 1 SYSTEM SWITCH - SPST
14 G18D060, 070,077, 090 R68GF0002 1 TRANSFORMER (115V-24V-40VA)
15 G18D060, 070,077, 090 R68CA0004 1 AUTO RESET LIMIT SWITCH, OPEN 140F - CLOSE 110F
16
G18D060 R86GF0096 1 BURNER AS EMBLY 60,000
G18D070 R86GF0095 1 BURNER AS EMBLY 70,000
G18D077 R86GF0092 1 BURNER AS EMBLY 77,000
G18D090 R86GF0094 1 BURNER AS EMBLY 90,000
17 G18D060, 070,077, 090 R68GF0005 1 HOT SURFACE IGNITER
22
G18 w/ H3BB & A3BB BLR R65BV0021R 1 MOTOR - 1/3 HP ECM 5 SPD
G18 w/A4BC BLR R65BV0023R 1 MOTOR - 3/4 HP ECM 5 SPD
23 ALL w/ A4AA BLR R86GF0056 1 MOTOR MOUNT AS EMBLY
24 G18D060, 070,077, 090 R69AB0001 1 BLOWER WHE L - 10 X 8
25 G18D060, 070,077, 090 R86GF0058 4 DOOR LATCH SET
26 SE ORIFICE CHART (TABLE 8) R72AG-*** 1 MAIN BURNER ORIFICE
27 G18D060, 070,077, 090 R87AF0010 1 BURNER MOUNTING PLATE
28 G18D060, 070,077, 090 R73GF0013 1 12-PIN HARNES FOR EMERSON BOARD
30 G18D060, 070,077, 090 R71FA0006 4 CONTROL BOARD STANDOFFS
G18D060, 070,077, 090 R87NNE001 1 FILTER RETAINER BRACKET
ALL R77GA0003 1 BURNER GASKET
ALL CA3B(A,B) R86GF00126-C 1 BLOWER AS EMBLY (1/3 HP ECM 5 SPD)
ALL CA4B(A,B,C) R86GF00127-CR 1 BLOWER AS EMBLY (3/4 HP ECM 5 SPD)
ALL CA(3,4)B(A,B,C) R73XA0021 1 ECM BLOWER WIRE HARNES
G18D060 G18HA0601 1 60,000 HIGH ALTITUDE ORIFICE KIT (0-5000 FT)
G18D060 G18HA0602 1 60,000 HIGH ALTITUDE ORIFICE KIT (6000-10000 FT)
G18D070 G18HA0701 1 70,000 HIGH ALTITUDE ORIFICE KIT (0-5000 FT)
G18D070 G18HA0702 1 70,000 HIGH ALTITUDE ORIFICE KIT (6000-10000 FT)
G18D077 G18HA0771 1 77,000 HIGH ALTITUDE ORIFICE KIT (0-5000 FT)
G18D077 G18HA0772 1 77,000 HIGH ALTITUDE ORIFICE KIT (6000-10000 FT)
G18D090 G18HA0901 1 90,000 HIGH ALTITUDE ORIFICE KIT (0-5000 FT)
Notes:
1) Contact factory if furnace heat exchanger needs replacing. 80044464
2) G18D Gas Furnace has 5 Year Limited Warranty on parts from Furnace Manufactured Date
3) All Products Shipped FOB From Ft Worth, TX Factory
Table 8: Replacement Parts List
