MORTEX G18D SERIES - SECTION 7: ACCESSORIES AND REPLACEMENT PARTS

MORTEX PRODUCTS INC 501 TERMINAL RD FORT WORTH, TX 76106 Page 23
SECTION 6: BLOWER PERFORMANCE
SECTION 7: ACCESSORIES AND REPLACEMENT PARTS
Furnace
Model
Number
Mtr
HP
Speed
Tap
CFM @
0.10”
W.C.
E.S.P
CFM @
0.20”
W.C.
E.S.P
CFM @
0.30”
W.C.
E.S.P
CFM @
0.40”
W.C.
E.S.P
CFM @
0.50”
W.C.
E.S.P
CFM @
0.60”
W.C.
E.S.P
CFM @
0.70”
W.C.
E.S.P
CFM @
0.80”
W.C.
E.S.P
CFM @
0.90”
W.C.
E.S.P
CFM @
1.00”
W.C.
E.S.P
G18D---AH3BC
G18D---CA3BC
1/3
T4 * 635 463 194 -- -- -- -- -- -- --
T3 964 901 814 734 630 516 361 109 -- --
T2 1134 1078 1007 943 857 778 680 566 422 --
T1 1286 1217 1157 1094 1026 957 880 756 593 299
G18D---CA4BC 3/4
T4 * 884 678 485 360 333 258 136 -- -- --
T3 1337 1280 1221 1145 1089 1018 955 890 823 629
T2 1553 1485 1415 1347 1258 1125 979 973 802 535
T1 1650 1537 1454 1366 1227 1166 1035 1021 853 578
Table 6: Blower Performance Chart – With Filters – Without Cooling Coil
* Speed tap T4 should only be used for the constant circulation mode.
Table 7: Accessories
PART NUMBER
DESCRIPTION NOTES
90-RJF1729-AL
ROOF JACK FOR FLAT METAL ROOF Height: 17” - 29”
90-RJF2551-AL
ROOF JACK FOR FLAT METAL ROOF Height: 25” - 51”
90-RJS1729-AL
ROOF JACK FOR 3/12 SLOPED ROOF Height: 17” - 29”
90-RJS2551-AL
ROOF JACK FOR 3/12 SLOPED ROOF Height: 25” - 51”
90-RJS3868-AL
ROOF JACK FOR 3/12 SLOPED ROOF Height: 38” - 68”
90-RJS6399-AL**
ROOF JACK FOR 3/12 SLOPED ROOF Height: 63” - 99”
CROWN ASSEMBLY & FIELD SUPPLIED SEALANT REQUIRED FOR EACH ROOF JACK BODY PURCHASED
90-RJCRWN-AL
CROWN ASSEMBLY, RJ, GAS All Roof Jacks
DUCT CONNECTOR WITH FLOOR BASE THAT MAY BE REQUIRED FOR EACH FURNACE (SEE INSTALLATION INSTRUCTIONS)
90-DCU0-01
1” - 4” DUCT CONNECTOR
90-DCU0-02
6” - 8” DUCT CONNECTOR
90-DCU0-03
8” - 12” DUCT CONNECTOR
FURNACE AND ROOF JACK ACCESSORIES
90-OUTXT16-AL
RJ 16” EXT OUTDOOR All Roof Jacks
90-INSXT10-AL
RJ 10” EXT INDOOR All Roof Jacks
90-RJS56
5-6/12 SLOPE ADAPTER All Roof Jacks
90-TRM-RNG
CEILING RING All Roof Jacks
R87JAZ002
DOOR, UPPER, ALL MODELS All Furnaces
R87JAZ003
DOOR, LOWER, “A” MODEL G18 Model A
R87JAZ005
DOOR, LOWER, “C” MODEL G18 Model C
