Morton M45 - Valve Parts List

Morton
®
Water Softener Installation & Operation Manual 27
Valve Parts List
K
ey
No.
Part No. Description
100 7224087 Screw, #8-32 x 1” (2 req.)
101 7286039 Motor (incl. 2 ea. of Key No. 100)
102 7231393 Motor Plate
103 0900857 Screw, #6-20 x 3/8” (3 req.)
104 7171250 Bearing
105 7283489 Cam & Gear
– 7331169
Drain Hose Adaptor Kit
(includes Key Nos. 106-110)
106
á
Clip, Drain
107
á
Hose Clamp
108
á
Drain Hose Adaptor
109
á
O-Ring, 15/16” x 1-3/16”
110
á
Flow Plug, 2.0 gpm
– 7185487 Seal Kit (includes Key Nos. 111-116)
111
á
O-Ring, 5/8” x 13/16”
112
á
O-Ring, 1-1/8” x 1-1/2”
113
á
O-Ring, 4-1/2” x 4-7/8”
114
á
Rotor Seal
115
á
Seal
116
á
Seal, Nozzle & Venturi
117 7174313 Bearing, Wave Washer
118 7185500 Rotor & Disc
– 7342712
Drain Plug Kit, 1”
(includes Key Nos. 115, 119 & 120)
119
á
Plug, Drain Seal
120
á
Spring
121 7337589 Clip, 1”, pack of 4
122 7342704
Installation Adaptor, 1”, pack of 2,
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
K
ey
No.
Part No. Description
123 7337597 O-Ring, 1-1/16” x 1-5/16”, pack of 4
– 7290931
T
urbine & Support Assembly,
including 2 O-Rings (See Key No.
123) & 1 ea. of Key Nos. 124 & 125
124
á
Turbine Support & Shaft
125
á
Turbine
126 7309811 Wire Harness, Sensor
127 7081201 Retainer, Nozzle & Venturi
128 7171145 Valve Body
129 7342649 O-Ring, 1/4” x 3/8”, pack of 2
130 1202600 Nut - Ferrule
– 7257454
Nozzle & Venturi Assembly
(incl. Key Nos. 127, 129 & 131-139)
131 7081104 Housing, Nozzle & Venturi
132 7095030 Cone Screen
133 1148800 Flow Plug, .3 gpm
134
7114533 Nozzle & Venturi Gasket Kit
7204362 Gasket Only
135 7084607 Flow Plug, .15 gpm
136 7146043 Screen
137 7167659 Screen Support
138 7170262 O-Ring, 1-1/8” x 1-3/8”
139 7199729 Cap
140 7175199 Wave Washer
141 7171161 Valve Cover
142 7342681 Screw, #10 x 2-5/8”, pack of 8
143 7305150 Switch
144 7140738 Screw, #4-24 x 3/4” (2 req.)
145 7214383
Bypass Valve Assembly, 1”,
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
