Valve Parts List
K
ey
No.
Part No. Description
– 7384691
M
otor, Cam & Gear Kit, 1”
(includes Key Nos. 100-102)
100
á
Motor
101
á
Cam & Gear
102 7224087 Screw, #8-32 x 1” (2 req.)
103 7231393 Motor Plate
104 0900857 Screw, #6-20 x 3/8” (3 req.)
105 7171250 Bearing
– 7331169
Drain Hose Adaptor Kit
(includes Key Nos. 106-110)
106
á
Clip, Drain
107
á
Hose Clamp
108
á
Drain Hose Adaptor
109
á
O-Ring, 15/16” x 1-3/16”
110
á
Flow Plug, 2.0 gpm
– 7185487 Seal Kit (includes Key Nos. 111-116)
111
á
O-Ring, 5/8” x 13/16”
112
á
O-Ring, 1-1/8” x 1-1/2”
113
á
O-Ring, 4-1/2” x 4-7/8”
114
á
Rotor Seal
115
á
Seal
116
á
Seal, Nozzle & Venturi
117 7174313 Bearing, Wave Washer
118 7185500 Rotor & Disc
– 7342712
Drain Plug Kit, 1”
(includes Key Nos. 115, 119 & 120)
119
á
Plug, Drain Seal
120
á
Spring
121 7337589 Clip, 1”, pack of 4
122 7342704
Installation Adaptor, 1”, pack of 2,
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
123 7337597 O-Ring, 1-1/16” x 1-5/16”, pack of 4
124 7214383
Bypass Valve Assembly, 1”,
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
K
ey
No.
Part No. Description
– 7
290931
Turbine & Support Assembly,
i
ncluding 2 O-Rings (See Key No.
123) & 1 ea. of Key Nos. 125 & 126
125
á
Turbine Support & Shaft
126
á
Turbine
127 7309811 Wire Harness, Sensor
128 7081201 Retainer, Nozzle & Venturi
129 7171145 Valve Body
130 7342649 O-Ring, 1/4” x 3/8”, pack of 2
131 1202600 Nut - Ferrule
132 7257454
Nozzle & Venturi Assembly
(incl. Key Nos. 128, 130 & 133-142)
133
á
Housing, Nozzle & Venturi
134
á
Cone Screen
135
á
Fill Flow Plug, 0.3 gpm
136
á
Gasket
137
á
Nozzle & Venturi Disc, Blue
138
á
Flow Plug, 0.15 gpm
139
á
Screen
140
á
Screen Support
141
á
O-Ring, 1-1/8” x 1-3/8”
142
á
Cap
¢
7298913
Repl. Nozzle, Venturi & Gasket Kit
(includes Key Nos. 130, 134, 136,
137 & 141)
143 7175199 Wave Washer
144 7171161 Valve Cover
145 7342681 Screw, #10 x 2-5/8”, pack of 8
146 7305150 Switch
147 7140738 Screw, #4-24 x 3/4” (2 req.)
148 7379785
Motorized Water Shutoff Valve,
including 1” NPT Nipple Ù
Questions? Call Toll Free 1-888-64 WATER (1-888-649-2837)
or visit www.mortonwatersofteners.com
When you call, please be prepared to provide the model and serial number,
found on the rating decal, located on the rim below the salt lid hinges.
¢ Not illustrated
