MotorGuide R3-30 User Manual

PRODUCT OVERVIEW
eng 7
R3‑30/R3‑40/R3‑45/R3‑55 MotorGuide Trolling Motor
a - Top housing
b - Extendable speed control tiller handle
c - Serial number
d - Positive and negative battery leads
e - Depth adjustment collar (R3‑45/55 model shown)
f - Tilt lock release lever (R3‑45/55 model shown)
g - Transom clamp screws
h - Column
i - Lower unit
j - Propeller
k - Clamp bracket (R3‑45/55 model shown)
l - Steering tension collar
m -Clamp bracket assembly (R3‑30/40 model shown)
n - Tilt lock release button (R3‑30/40 model shown)
o - Collar (R3‑30/40 model shown)
a
b
c
d
e
f
g
h
i
j
k
l
g
n
o
m
l
