MotorGuide R3-30 User Manual

TROLLING MOTOR INSTALLATION AND OPERATION
eng 15
1. Firmly grasp the trolling motor head/column and press on the tilt
lock release pin/lever.
a - Tilt lock release lever (R3‑45
and R3‑55 models shown)
b - Latch pin
2. Adjust the angle of the motor to the desired position.
3. Release the tilt positioning pin/lever. Verify that the latch pin is
securely engaged.
Adjusting the Steering Tension
1. Turn the steering tension knob clockwise to increase steering
effort.
a
b
45077
