TROLLING MOTOR INSTALLATION AND OPERATION
14 eng
2. When the desired tilt position is achieved, release the tilt lock
release pin/lever. Verify that the latch pin is securely engaged.
a - Tilt lock release lever (R3‑45 and R3‑55 model shown)
b - Latch pin
c - Tilt lock release pin (R3‑30 and R3‑40 model shown)
DEPLOYING THE MOTOR
!
CAUTION
Moving parts, such as hinges and pivot points, can cause serious
injury. Keep away from moving parts when stowing, deploying, or
tilting the motor.
a
b
c
b
45134
