3.3.2
Pelco Sarix Modular Cameras and Main Unit
This is the most discreet camera solution available across the Pelco camera portfolio, offering two imager
module options to capture scenes and people of interest. The Sarix Modular camera is NDAA-compliant and
has open connectivity with leading 3rd party VMS and Pelco VideoXpert.
Figure 4: Pelco Sarix Modular Cameras and Main Unit View
For current product specifications and instructions see the Pelco website.
3.3.2.1
Pelco Sarix Modular Camera Unit Components
The following table describes the multiple components of the Pelco Sarix Modular Camera unit.
Table 1: Pelco Sarix Modular Camera Unit Components
Component Image Details
Pelco Sarix Modular 2 Port
Main Processor Unit
● The Main Processor Unit serves as the
base unit for the modular system.
● The modular cameras and microphone
are connected to the Main Processor
Unit.
● The Main Processor Unit connects to
the PoE+ Switch.
● Every interview room system with mod-
ular cameras has one Main Processor
Unit per room.
● Each Main Processor Unit can connect
to up to two cameras (Microbullet or
Pin Hole Imager). Cameras can be
mixed and matched (one of each, or
two of a kind).
MN010550A01-A
Chapter 3: Interview Room Hardware Component Details
11
