Component Image Details
Pelco Sarix Modular 3MP
Fixed Microbullet Camera
● The Microbullet Camera can be posi-
tioned for discreet recording, which
is especially useful for sensitive inter-
views and soft rooms.
● For example, it may be set up on a
shelf or within a tissue box.
Pelco Sarix Modular 3MP
Pin Hole Imager Camera
● The Pin Hole Imager Camera is anoth-
er discreet option.
● Unlike the Microbullet Camera, the Pin
Hole Imager Camera can be installed
on a wall.
Pelco Modular 5m HD BNC
Cables
(No image available) Each camera is connected to the Main Pro-
cessor Unit with an HD BNC Cable.
To set up the modular cameras:
1. Follow the hardware instructions to assemble and mount the modular cameras.
2. Connect the modular cameras to the main unit with the HD BNC cables.
3. Connect the main unit to the PoE+ with an Ethernet cable.
To configure zoom and focus, review the “Accessing Camera Settings” section in the Sarix Modular Camera
Operations Manual.
3.4
Louroe Audio Monitoring System
The ASK-4
®
Audio Monitoring System is a single zone audio monitoring system designed ideally for
connection to IP cameras or NVRs. When ceiling mounted, it can pick up sounds within a 30′ diameter
circle. The model IF-1 interface adapter connects to the microphone, supplies power to the microphone and
drives audio into the input of the recording device.
For more information on IF-1 interface adapter, see https://www.louroe.com/product/if-1/.
MN010550A01-A
Chapter 3: Interview Room Hardware Component Details
12
